Intel Tiger Lake-H COM-E Core Board
Support Intel 11th Gen. Core H series CPU, default i7-11850H
Support 2 x DDR4 SO-DIMM, up to 64G/3200Mhz
Support 4 x SATA 3.0
5 display port, 3 x DD1 (can configure to HDMI/DP), 1 x DDI (can configure to VGA)
1 x EDP to LVDS (can configure to EDP)
4 x USB 3.2, 8 x USB 2.0, 1 x PCIe x 16 (can configure to 1x16,2x8,1x8+2x4)
8 x PCIe x 1 (can configure to x4 or x2)
COMe Type 6 protocol, size 125mmx9.5mm
