Features
• INTEL KABY LAKE platform
• Supports LGA 1151 6th and 7th generation processors
• 4 MINI PCIE slots, can carry 4 Movidius graphics accelerator cards
• Dual channel SO-DIMM DDR4 memory design (supports up to 32GB)
• INTEL I211 network card
• Silent double fan + copper tube heat sink design
| System Core | CPU | Support the seventh generation Intel kaby lake i3/i5/i7 processor, compatible with the sixth generation | |||
| Chipset | Intel B250 | ||||
| Memory | 2* DDR4 SO-DIMM slots support up to 32G expansion | ||||
| I/O | Graphics | 1* HDMI | |||
| Ethernet | 2 Gigabit Ethernet ports, Intel i211 chip, adaptive 10M/100M/1000M; support wake-up on LAN and PXE function | ||||
| Serial | 1* COM (DB9 interface), RS485 signal, male | ||||
| USB | 6* USB3.0 | ||||
| Audio | 1* Line OUT, 1* Mic (front) using ALC662 chip | ||||
| DI/O | / | ||||
| WOL | / | ||||
| Miscellaneous | LED Indicators | 1*power LED red, 1*HDD green | |||
| on-off | Function: 1*Power switch (supports power-on and automatic boot) | ||||
| Control | / | ||||
| Expansion | WLAN | 1*M.2 slot can support Wi-Fi/BT module (Above Bluetooth 4.0) | |||
| MXM | / | ||||
| Storage | 2.5 inch SATA | not support | |||
| MicroSD | Front support 1*MicroSD | ||||
| SSD | 1*M.2 slot supports 2242/2280 PCIe SSD compatible with SATA | ||||
| Other interface | LPC | / | |||
| Physica | Dimensions | 170(D)*196(W)*42(H) mm | |||
| kg | 1.5KG | ||||
| Mounting | desktop | ||||
| DC FAN | have | ||||
| Power Requirements | DC input | DC 19V-24V input (support 220W adapter) 4P plug | |||
| DC output | / | ||||
| Environment | Operation Temperature | -10-40℃ | |||
| Operating Humidity | 10%～90% | ||||
| Storage Temperature | -40-80℃ | ||||
| Storage Humidity | 10%～90% | ||||
| Reliability | / | ||||
| Safety Certificate | / | ||||
| OS | Microsoft | Support Win7, Win10, Win11 | |||
| Linux | Support Linux system | ||||
