Features
• AMD Radeon R5 230 Display Chip
• 1G DDR3 graphics memory
• HDMI+DVI+VGA display interface
• Type A size
• MXM3.1 slot
| Processor System | GPU | AMD Radeon R5 230 | ||||
| Graphic Architecture | Caicos | |||||
| Shader | 160SP | |||||
| GPU clock | 625MHz | |||||
| Memory | Technology | 1G DDR3 | ||||
| Interface Width | 64bit | |||||
| Bandwidth | 11.2GB/s | |||||
| Graphics | DP | HDMI1.4+DVI+VGA | ||||
| Bus | PCI express 3.0 | MXM3.1 | ||||
| Power Consumption | Max Power Consumption | 25W | ||||
| Power Supply | 350W | |||||
| Environment | Operating | Storage Temperature | ||||
| Temperature | 0~45°C | -20~75°C | ||||
| Humidity | 0~95%（non-condensing） | 10~90% | ||||
| Physica | Dimensions | 70*82mm | ||||
| Form Factor | MXM3.1 | |||||
| warranty | 3 Years | |||||
| OS | Microsoft | Windows 7/8/8.1/10 32/64bit | ||||
| Linux | Linux 32/64bit | |||||
