RTX4080m MXM Module
MM4080B6-12G is a high-performance MXM graphics card based on the NVIDIA Ada Lovelace architecture. Equipped with 12GB GDDR6 VRAM and 7427 CUDA Cores, it supports PCIe 4.0 x16 and multi-channel 8K display, delivering powerful graphics computing power for high-end embedded applications.
Product Features
- NVIDIA Ada Lovelace Architecture, equipped with NVIDIA GeForce RTX4080 Max-Q GPU
- 12GB GDDR6 192-bit VRAM, 432GB/s memory bandwidth
- 7427 CUDA Cores, 232 Tensor Cores, 80 RT Cores
- MXM 3.1 Type B form factor (105×82mm), PCIe 4.0 x16 interface
- 2×DP 1.4++ + HDMI 2.1 + eDP + HDMI multi-output
- TDP 125W (80W optional); supports Windows 10/11 and Linux
MM4080B6-12G is equipped with NVIDIA GeForce RTX4080 Max-Q GPU built on the Ada Lovelace architecture. It features 7427 CUDA Cores, 232 Tensor Cores and 80 RT Cores, delivering single-precision floating-point performance up to 30 TFLOPS. Fitted with 12GB GDDR6 192-bit VRAM and 432GB/s memory bandwidth, it delivers smooth performance for high-resolution gaming, 3D rendering and AI inference workloads.
It adopts the MXM 3.1 Type B form factor (105×82mm) with PCIe 4.0 x16 high-speed bus. It supports 2×DP 1.4++, 1×HDMI 2.1, 1×eDP and 1×HDMI outputs, with a maximum display capability of 8K@120Hz. TDP is 125W (80W optional). Compatible with Windows 10/11 and Linux, it is ideal for high-performance embedded devices, professional graphics workstations and edge AI inference platforms.
| 产品型号 | MM4080B6-12G (RTX4080m) |
| GPU架构 | NVIDIA Ada Lovelace |
| GPU型号 | NVIDIA GeForce RTX4080 Max-Q |
| 显存容量 | 12GB |
| 显存类型 | GDDR6 |
| 显存位宽 | 192bit |
| 显存带宽 | 432GB/s |
| 核心频率(Base/Boost) | 795/1350MHz |
| CUDA核心 | 7427 |
| Tensor Core | 232 |
| RT Core | 80 |
| TMUs | 232 |
| ROPs | 80 |
| SM Count | 58 |
| PCIe接口 | PCI Express 4.0 x16 |
| MXM规格 | MXM 3.1 Type B |
| 尺寸 | 105 × 82 mm |
| TDP功耗 | 125W（可选80W） |
| 显示输出 | 2×DP 1.4++ + HDMI2.1 + eDP + HDMI |
| 最大分辨率 | DP: 7680×4320@120Hz / HDMI: 8K@60Hz |
| 操作系统 | Windows 10/11 64bit、Linux |
| 工作温度 | 0°C ~ 45°C |
| 存储温度 | -20°C ~ 75°C |
| 工作湿度 | 0%~95%（非凝结） |
| 存储湿度 | 10%~90% |
| 供电电压 | DC 12~19V，3.3V&5V±5% |
| 单精度浮点 | 30.0 TFLOPS |
| 双精度浮点 | 471.6 GFLOPS |
| DirectX | 12 Ultimate (12_2) |
| OpenGL | 4.6 |
| OpenCL | 3.0 |
| Vulkan | 1.3 |
| Shader Model | 6.7 |
| CUDA版本 | 8.6 |
Model: MM4080B6-12G | VRAM: 12GB GDDR6 192-bit | Interface: MXM 3.1 Type B | TDP: 125W (80W optional)
