Solution Intro: Industrial AI Motherboard + High-Performance MXM GPU
HPC Platform:The EMA-7102 motherboard is equipped with Intel 9th Gen Coffee Lake-H processors(options:i7-9850H / i7-8850H / i5-8400H,max turbo frequency up to 4.6GHz).
MXM Discrete GPU Acceleration:On-board MXM 3.1 Type-B graphics interface supports the MM3080B6-16G graphics card(based on NVIDIA Ampere architecture,mobile-verison RTX 3080,6144 CUDA cores,16GB GDDR6 video memory,256-bit bus,448GB/s bandwidth).The graphics card features PCle 4.0×16 and delivers up to 135W of graphics computing power with approximately 17.5 TFLOPS single-precisison floating-point performance.It greatly accelerates image rendering,deep-learning inference and mulit-channel videpo processing.
Industrial Rugged Design:Compact mITX(170 x 170mm)footprint.Wide-temperature support(0-50°C;-20°C / -40°C optional),wide-voltage 12-24V DC input for battery-operated mobile equipment.Rigorously selectecd and burn-in-tested components deliver vibration,shock,dust and moisture resistance to withstand harsh field harsh field and vehicle-mounted conditions.
Multi-Display Control Support :The motherboard natively provides five display outputs(HDMI,DP,eDP,LVDS,optional HDMI/DP).Combined with four DisplayPort outputs from the MXM GPU (configurable for DP++ or HDMI 2.1),a single card supports resolutions up to 7680 x 4320@120Hz.It can drive dual-screen or triple-screen displays simultaneously,perfectly matching the UI requirements of dual-display rugged laptops.
Solution Highlights
Stable Operation in Extreme Enviroments :Both the motherboard and GPU adopt industrial-grade components.They support -20 °C ~ 70°C wide-temperature storage and 0 ~ 50°C operating temperature(-40°C extendable).Equipped with thermal pads and customized solutions,the system maintains stable performance under harsh conditions including high/low temperature,humidity and dust,ensuring uninterrupted field rescure and military operations.
Powerful GPU Acceleration for Real-Time AI Inference : The MM3080B6-16G GPU integrates 192 Tensor Cores and supports CUDA 8.6,enabling efficient execution of AI algorithms such as image recognition,object detection and terrain analysis.
Rich Expansion & Connectivity : The EMA-7102 motherboard comes with 2 x Gigabit Ethernet ports,3 x USB 3.1,Type-C(display and data support),2 x USB 2.0,1 x RS232, 1 x SATA 3.0,3 X M.2(Key-M/B/E) and a SIM card slot.It allows flexible intergration of peripherals such as 4G/5G,Wi-Fi 6,Beidou/GPS modules,infrared night-vision devices and life detectors to meet multi-functional integration requirements.
Stable and Reliable Power & Thermal Solution :It supports 12-24V wide-voltage input,compatible with vechicle-mounted power supplies and battery-powered operation.The MXM GPU features dynamic power adjustment(85W/110W/135W optional).Combined with high-efficiency thermal conduction and active cooling design,it guarantees consistent performance and service life under long-term full-load operation.
Application Scenarios
This solution applies to dual‑display rugged laptops, handheld rugged tablets, vehicle‑mounted computers, field survey terminals, emergency rescue command devices and UAV ground stations. Powered by EMA‑7102 motherboard and MM3080B6‑16G GPU, featuring high performance, industrial‑grade reliability and multi‑display output, it provides a robust foundation for data collection, information processing and decision support in harsh environments, helping users address mission‑critical challenges.
