Core Module

• Intel 6th Gen Core U Series, 2 Cores / 4 Threads, 15 W low power consumption
• COM Express Type 6 Compact, 95 × 95 mm form factor
• DDR4 up to 16 GB + PCIe x4
• Gigabit Ethernet + SATA 3.0 + multi-display support
• TPM 2.0 security chip, industrial wide-temperature reliability

• Intel Elkhart Lake, ultra-low power 6 ~ 10 W
• COM-Express Type 10, 84 × 55 mm
• Onboard 16 GB LPDDR4x + 64 GB eMMC
• 2.5 GbE + PCIe x4 + 2 × SATA 3.0
• 4K display output, ideal for light industrial and IoT applications

1. 11th Gen Intel Tiger Lake-U,up to 4 cores/8 threads
2. COM-Express Type 6 Compact，95×95mm
3. DDR4 3200MHz up to 64GB + Iris Xe Intergrated Graphics
4. Flexible display solution with 3×DDI + eDP/LVDS
5. PCIe x4 + Gigabit Ethernet + Rich Industrial Interfaces

• Intel 12th/13th Gen Core Processors,
• 2×DDR5 SO-DIMM, up to 64GB
• PCIe Gen4 PEG + multi-lane PCIe Gen3 expansion
• 4 independent displays: LVDS/eDP + 3×DDI + VGA
• 95×95mm standard size, supports Windows/Linux

• Intel Core U300E Processor, 5 cores 6 threads, 15W low power consumption
• COM-Express Type 6 Compact, 95×95mm compact size
• DDR5 4800MHz, up to 64GB, balancing performance and energy efficiency
• PCIe Gen4 multi-lane expansion + 2.5GbE high-speed network
• Triple display output + abundant industrial interfaces, ideal for HMI applications

• Intel N97 / i3-N305 processors, up to 8 cores
• COM-Express Type 10, ultra-small size of 84×55mm
• Onboard LPDDR5 16GB + 2.5GbE + eMMC
• Flexible PCIe configuration with strong expandability
• Wide voltage 4.75V~20V, ideal for low-power embedded applications

• Intel Xeon D processor, Broadwell-DE server-grade architecture
• COM-Express Type 7, 95×125mm
• DDR4 up to 64GB + 10G
• PCIe x8 + PCIe x16 + 7×PCIe x1
• 2.5GbE/10G network + Dual SATA3.0
